NocPix ACE H50R Thermal Rifle Scope - 12um 640x512 <15mK NETD w/ LRF & Ballistic Calculation

Precision meets power. Built for hunters who demand excellence.
The NocPix ACE H50R is the most advanced thermal riflescope in the ACE series — engineered for long-range detection, accurate shot placement, and all-weather reliability. Featuring a powerful 640×512 HD sensor with ≤12mK sensitivity, integrated Class 1 Laser Rangefinder, ballistic calculator, and Reality+ image enhancement, this optic gives you complete confidence in the field.

A 50mm f/0.9 objective lens ensures brighter, sharper visuals by transmitting 20% more light than standard optics. Combined with a round 2560×2560 AMOLED display and advanced Vision+ zoom, the ACE H50R delivers distortion-free image quality even at 24× magnification.

Whether you're tracking heat signatures across vast terrain, lining up a 300-yard shot in the dark, or recording your hunt, the H50R is your all-in-one solution.

🔧 Tech Specs

Sensor & Optics

• Sensor Resolution: 640 × 512 (VOx)

• Pixel Pitch: 12 μm

• NETD: ≤12mK

• Frame Rate: 60Hz

• Lens: 50mm f/0.9

• Magnification: 3× base – 24× digital

• Ocular Zoom: 1× – 3×

• Field of View: 8.8° × 7.0°

• Detection Range: 2600m

• Diopter Range: -5 to +5D

• Eye Relief: 50mm

• Exit Pupil: 8mm

Display

• Type: 1.03" Round AMOLED

• Resolution: 2560 × 2560

• Reality+ AI Image Processing: Yes

• Vision+ Optical Zoom System: Yes

• Picture-in-Picture (PIP): Yes

Laser Rangefinder & Ballistics

• Rangefinder: Class 1 Laser

• Measuring Range: 1200m ±1m

• Ballistic Calculator: On-screen reticle adjustment

• Integrated Optical Axis Alignment: Yes

Power & Recording

• Battery: Built-in 4000mAh + Replaceable 18650

• Runtime: Up to 7 hours

• Recoil-Activated Video: Yes

• Recording: Photo & Video (64GB storage)

• USB-C Charging: Yes

• Wi-Fi & App Support: Yes

• Microphone: Yes

Build & Durability

• Material: High-strength aluminium alloy

• Recoil Resistance: Up to 6000 J

• Mount Type: 30mm Tube

• Waterproof Rating: IP67

• Operating Temperature: -20°C to +50°C

• Weight: 1120g

• Dimensions: 365 × 90 × 68 mm

---

💬 Why We Recommend It

The ACE H50R is ideal for serious shooters and professionals who demand pinpoint accuracy and unmatched clarity. The addition of a laser rangefinder and ballistic calculator sets it apart from traditional thermal scopes — making it the perfect tool for long-range, ethical shooting in any light, any weather.

📦 What’s in the Box

• NocPix ACE H50R Thermal Rifle Scope (640×512)

• Integrated Class 1 LRF

• Mounting Rings – 30mm

• USB-C Charging Cable

• Quick Start Guide

• Cleaning Cloth

• Protective Carry Case
